Intelligent Robot Contest 2001 Rule Book
Latest rule book
Soap Box detail
- pattern applied for soap
box
(In this PDF, the image for one soapbox contains two different
characters such as A and B. It is only because of paper size, and
we use soapbox with same letter in two faces, such as A and A,
as in rule book.)
This PDF file is generated from pattern image that will be
pasted to soap box. The pattern is almost same with that used in
contest, but please be careful to color. We pay effort to make
its color red, but it will be impossible to achieve true red in
industrial standard. Of course, the color of objects is deeply
depend of lighting of contest hall. You should assume that
the color of soapbox will be red a little near to vermilion or
purple.
- a sample of soap box
We will use this kind of box as object. Please note that this is
only a sample (there will be made some changes when we have some
trouble to use this one).
Major change from 2000
- We used onlyYellow Tennis Ball.
- We have created "Truely Random Area".
- The position of "Tower" becomes random.
- In Technical course, we introduce a new challenging feature
that called "Technical Theme". In 2001, "Vision" is selected to
this theme. If you used vision recognition in searching objects,
etc., you will have additional score by judge. We also write
a letter of 'A','B','C','D' on each soap box respectively.
Please challenge to read it and demonstrate that your robot
can read it to judges and audience.
Changes reports
- 2000/9/26
Japanese rule is presented.
- 2000/10/06
English rule is presented.
- 2000/11/18
Description of 'using vision'(page 2) and object detail
(page 10)is corrected.
- 2000/11/19
More information about character on soap-box.
- 2001/4/10
The rule has been almost decided, only adding little notice.
(I added the fact that competition table and other attachments are painted)
- 2001/5/14
I fixed the rule and becomes not preliminary one
because there has been no complaint. OK?
I must say, the deadline is tomorrow!
- 2001/10/27
Some of dimensions of competition tables are
changed when we renewaled it. Please make sure to refer
rulebook. Arrangement of competition table is changed maximum 15mm
and goalbox is largely changed.
